Здравствуйте Друзья.
Сегодня у нас на обзоре 4-е и последнее из доступных на данный момент беспроводных реле Switch Breaker WiFi X для экосистемы умного дома Mijia Mi Home.
Я уже делал обзоры на двухканальное WiFi реле Yeelight Smart Dual Control Module и одноканальное Bluetooth Mesh реле PTX Sle Bluetooth intelligent switch представленные в 2020 году. Также до сих пор актуально двухканальное ZigBee реле Aqara Wireless Relay представленное в 2018 году.
Теперь давайте рассмотрим очередную новинку…
Поставляется устройство в тонкой картонной коробке с цветными логотипами Mijia и Xiao Ai на передней стороне и основными характеристиками сзади. Размер коробки в притык самого реле, поэтому повредить коробку можно только вместе с устройством.
Надписи все на китайском — устройство только для региона Китай.
Комплектация самая минимальная из возможных — коробка и само реле.
Само реле имеет прямоугольную форму со скругленными краями и выполнено из белого матового пластика. В нижней части корпуса присутствуют “ушки” для фиксации устройства на поверхности с помощью саморезов.
Корпус разборный и состоит из 3-х частей. Маленькая крышечка зафиксированная с помощью самореза предназначена для доступа к клеммам.
После ее снятия можно отсоединить и большую крышку, которая фиксируется с помощью защелок.
Саму плату достать не получилось, так как кроме защелок она зафиксирована еще и каким то клеем к нижней части корпуса.
Качество сборки и пайки, судя по доступной части, хорошее.
Немного “смущают” винтики на клеммных колодках — они только под плоскую отвертку… Размер самого реле также вызывает недоумение — двухканальное реле от Yeelight оказалось меньше героя обзора.
Управление реле так же скудное по сравнению с другими — доступно только беспроводное включение/выключение с помощью смартфона, беспроводных кнопок или по таймерам-сценариям. По этому схема подключения очень простая, два контакта входных, два — выходных. Причем нулевая линия сквозная.
Характеристики:
Модель: XEE61
Интерфейс управления: WiFi
ID: leshi.switch.v002
Модуль связи: ESP-WROM-32D
Максимальная мощность нагрузки: 3500 Вт или до 350 Вт LED светильники, но не более 16 А
Размер: 60 * 43 * 30
Каналов управления: 1
Управление: через приложение со смартфона, голосовое управление XiaoAI , любыми беспроводными выключателями из экосистемы Xiaomi по сценариях.
Так как устройство работает по протоколу WiFi, для подключению к умному дому Xiaomi никаких шлюзов не нужно, только роутер и интернет.
При первом подключении я использовал небольшой сетевой кабель с оголенными проводами с одной стороны. Соблюдать полярность при отсутствии нагрузки не обязательно. Но уже в момент установки настроенного реле все таки рекомендую подключать питание соответственно надписать на крышке.
После подачи питания, включаем Bluetooth (по нему происходит передача настроек сети) и запускаем приложение Mijia Mi Home на смартфоне, которое автоматически находит новое устройство.
Во время подключения, следуем указаниям приложения.
После удачного подключения приложение загрузит плагин для управления.
В случае неудачного подключения, рекомендуется 5 раз переключить питание, после чего реле несколько раз включится/выключится и выйдет в готовность. Далее повторно следуем указаниям.
Стоит отметить что кнопки Reset как и какой нибудь световой индикации работы на устройстве нету…
Плагин нового реле такой же скромный как и его функционал, в главном окне доступны включение/выключение и настройка таймеров.
При нажатии в правом верхнем углу иконки (…) попадаем в меню настроек.
Здесь нам доступны установка состояния реле при пропадании питания, изменение имени и положения устройства, проверка и установка обновлений и т.п.
В плане автоматизации реле может выступать как в роли условия так и исполнителем, что позволяет расширить функционал сценариев в связке с другими смарт устройствами.
Заключение
Итак, последнее реле получилось комом…
Из минусов:
-
слабый функционал… реле одноканальное и доступно только беспроводное управление.
-
отсутствие дополнительной внешней антенны значительно сокращает расстояние до роутера.
-
отсутствие кнопки Reset и световой индикации.
-
цена данного реле практически идентична двухнакальным реле от Aqara и Yeelight, которые еще поддерживают и управление механическими выключателями. Возможно со временем цена изменится, так как на момент покупки и написания обзора, устройство доступно только у одного продавца.
-
то же касается и размеров… устройство получилось больше при меньшем количестве каналов и функций.
К плюсам можно отнести стабильную работу устройства, отсутствие перегрева и неплохое качество изготовления.
Buy From Aliexpress ➤ http://shp.pub/67gf8x http://shp.pub/67gfb9
смотрите также
двухканальное WiFi реле Yeelight Smart Dual Control Module (Обзор)
одноканальное Bluetooth Mesh реле PTX Sle Bluetooth intelligent switch (Обзор)
одноканальное Julun WiFi Smart Switch — Обзор
одноканальное Xinguang Bluetooth MESH Switch (BLE MESH) — Обзор
одноканальное Zemismart ThoughtHome smart switch module (WiFi) — Обзор
методы реализации “умного” освещения – статья
P.S. следить за выходами новых обзоров а также за новинками и новостями Xiaomi теперь можно и в telegram канале…
Welcome to our blog! Today, we will be exploring the world of circuit breakers and taking a closer look at the differences between smart breakers and regular breakers in electrical panels. As technology continues to advance, the field of electrical systems is also evolving. Smart circuit breakers are gaining popularity for their enhanced features and capabilities.
Smart Breakers: Embracing the Future of Electrical Systems
Technology is evolving. Smart circuit breakers are the newest type of circuit breakers to upgrade home. They are revolutionizing the way we manage and optimize our electrical systems. Let’s examine what makes a smart breaker special. We will explore the features and capabilities it brings to the table.
Definition of Smart Breakers
Smart breakers, also known as intelligent or digital circuit breakers. They are a type of circuit breaker that incorporates advanced technology for enhanced functionality. These products are designed to provide more than basic protection from electrical faults. They offer extra features and capabilities that enhance the performance, efficiency, and safety of electrical systems.
Features and Capabilities of Smart Breakers
Smart breakers come equipped with a wide range of features and capabilities that set them apart from regular breakers. Here are some of the key features of smart circuit breakers:
1. Remote Control and Monitoring
Smart breakers can be controlled and monitored remotely through various means, such as smartphone apps, web interfaces, or smart home systems. Users gain real-time visibility and control over their electrical systems. This is true even when they are away, offering convenience and flexibility.
2. Energy Management and Optimization
Smart breakers can analyze energy usage in real time. This provides insights into energy consumption patterns. It also enables users to manage their energy usage more efficiently.
Smart breakers can integrate with renewable energy sources and smart grid systems. This integration allows for advanced energy management and optimization strategies.
3. Load Balancing and Demand Response
Smart breakers can intelligently distribute electrical loads across different circuits, helping to balance the load and prevent overloading. Smart circuit breakers can take part in demand response programs. They adjust energy usage during peak periods to lower electricity costs. This also lessens the pressure on the electrical grid.
4. Safety and Diagnostics
Smart breakers can provide advanced safety features such as arc fault detection, ground fault detection, and circuit health monitoring. They can offer diagnostic capabilities, such as fault detection, predictive maintenance alerts and troubleshooting assistance. This helps to prevent electrical hazards and optimize system performance.
Examples of Smart Breaker Technologies in the Market
Smart circuit breakers are transforming the landscape of electrical systems with their advanced features and capabilities. They offer increased energy efficiency, enhanced safety and convenience, and potential cost savings. There are various smart circuit breaker technologies available in the market today, including:
1. WiFi smart breakers
These WiFi circuit breakers connect to a home’s WiFi network, allowing for remote control and monitoring through smartphone apps or web interfaces.
2. Zigbee and Z-Wave smart breakers
Smart circuit breakers use Zigbee or Z-Wave wireless communication protocols. These protocols are commonly used in smart home systems. They enable integration with other smart devices and systems.
3. IoT-based smart breakers
Smart circuit breakers are part of an Internet of Things (IoT) ecosystem. They communicate with other IoT devices and cloud-based platforms. This communication is used for advanced energy management, load balancing, and diagnostics.
Regular Breakers: Understanding the Basics
Smart circuit breakers are becoming more popular due to their advanced features. However, it is essential to understand the basics of regular breakers. These have been used in electrical systems for many years.
Definition of Regular Breakers
Regular breakers, also known as traditional or conventional circuit breakers, are the standard circuit breakers that have been used in electrical systems for many years. They are designed to protect electrical circuits from overloads, short circuits, and ground faults, providing essential safety functions.
Traditional Functions of Regular Breakers
1. Overload Protection
Regular breakers are designed to trip and interrupt the flow of electricity when the current exceeds the rated capacity of the breaker for an extended period of time. This protects the electrical circuits and prevents damage to the wiring and devices connected to the circuit.
2. Short Circuit Protection
Regular breakers are also designed to trip and interrupt the flow of electricity when there is a short circuit. It’s a direct connection between the hot and neutral wires or between the hot wire and the ground. This prevents excessive current flow and potential damage to the electrical system.
3. Ground Fault Protection
Regular breakers may also include ground fault circuit interrupter (GFCI breaker) functionality. It detects and interrupts the flow of electricity when there is a ground fault, such as a current leakage to the ground. This helps prevent electrical shocks and protects against electrical hazards.
Limitations of Regular Breakers
While regular breakers serve their basic protective functions, they have some limitations compared to smart circuit breakers. Here are a few of the limitations of regular breakers:
1. Lack of Remote Control and Monitoring
Regular breakers do not have remote control and monitoring capabilities. It means users have to physically access the breaker panel to manually operate or check the status of the breakers. This can be inconvenient and time-consuming, especially in large or complex electrical systems.
2. Limited Energy Management Capabilities
Regular breakers do not have advanced energy management features such as real-time energy monitoring, load balancing, or demand response capabilities. This makes it challenging to optimize energy usage and achieve maximum efficiency in electrical systems.
3. Inability to Optimize Load Balancing and Demand Response
Regular breakers do not have the ability to intelligently distribute electrical loads or participate in demand response programs. This may result in uneven load distribution and missed opportunities for cost savings and energy optimization.
Comparison: Smart Breakers vs Regular Breakers
Now that we have explored the features and capabilities of smart breakers and regular breakers separately. Let’s compare them to understand their key differences.
Key Differences between Smart Breakers and Regular Breakers
1. Remote Control and Monitoring Capabilities
One of the significant differences between smart breakers and regular breakers is the ability to remotely control and monitor the breaker status. Smart circuit breakers can be operated and monitored remotely through a smartphone app or a web interface. It allows users to have real-time visibility and control over their electrical system. On the other hand, regular breakers require manual operation and physical access to the breaker panel for monitoring and control.
2. Energy Management and Optimization Features
Smart breakers offer advanced energy management and optimization features, such as real-time energy monitoring, load balancing, and demand response capabilities. These features enable users to optimize their energy usage, reduce energy waste, and potentially achieve cost savings. Regular breakers, on the other hand, lack these advanced energy management features.
3. Load Balancing and Demand Response Capabilities
Smart breakers have the capacity to manage electrical loads. They also have the ability to take part in demand response programs. These programs let them adjust their energy usage during peak demand times or according to predefined settings. Regular breakers do not have this capability, resulting in uneven load distribution and missed opportunities for cost savings and energy optimization.
4. Safety and Diagnostic Functionalities
Smart breakers often come with additional safety features and diagnostic functionalities, such as fault detection, self-testing, and diagnostics. These features can help identify potential issues in the electrical system and proactively address them, enhancing safety and reliability. Regular breakers do not have these advanced safety and diagnostic capabilities.
Advantages of Smart Breakers over Regular Breakers
1. Enhanced Energy Efficiency and Cost Savings
Smart breakers have advanced energy management features. These include real-time energy monitoring, load balancing and demand response capabilities. These features can increase energy efficiency and potentially lead to cost savings. By optimizing energy usage and reducing energy waste, users can lower their electricity bills and achieve long-term cost savings.
2. Improved Safety and Convenience
The remote control and monitoring capabilities of smart circuit breakers provide enhanced safety and convenience. Users can monitor and control their electrical system remotely, using a smartphone or web interface. This reduces the need to physically access the breaker panel.
Smart breakers have safety and diagnostic functionalities. These can detect potential issues and improve the electrical system’s safety and reliability. This proactive approach helps protect the system.
3. Increased Optimization and Flexibility
Smart breakers offer load balancing and demand response capabilities, which provide increased optimization and flexibility in managing electrical loads. Users can distribute loads intelligently and participate in demand response programs. It allows them to optimize energy usage based on their preferences and needs.
Limitations and Considerations of Smart Breakers
1. Higher Cost Compared to Regular Breakers
One of the limitations of smart circuit breakers is their higher cost compared to regular breakers. Smart breakers come with advanced features and capabilities. However, they come at a high price. This may be an issue for consumers on a budget or for applications with a limited budget.
2. Dependence on Internet Connectivity and Technology
Smart circuit breakers rely on internet connectivity and technology for remote control, monitoring, and advanced features. Dependence on technology may be a limitation in areas with unreliable or limited internet connectivity. It could also be an issue in cases where technology failures have the potential to affect the functioning of smart breakers.
3. Security and Privacy Concerns
The remote control and monitoring capabilities of smart circuit breakers raise security and privacy concerns. Users need to ensure that proper security measures are in place, such as strong passwords and encryption, to protect against unauthorized access or data breaches.
Conclusion
Smart breakers are a significant advancement in electrical systems. They offer advanced functionalities and features which can improve energy efficiency, safety and convenience. Users must carefully consider their needs before making a decision about smart circuit breakers.
It is important to evaluate the limitations and costs associated with this technology. Smart breakers can be a valuable addition to modern electrical systems. Proper consideration should be given to ensure optimized energy usage, improved safety and increased convenience.
Contact:
AT-ELE
sale@at-ele.com
www.at-ele.com
Умное мини вайфай реле для умного дома Туя Смартлайф 220В 3500 Ватт максимальной нагрузки очень компактный переключатель WiFi выключатель
- Свободно помещается в стандартный подрозетник
- Для подключения нужна нейтральная линия
- Подключается к умному дому Tuya или Smartlife напрямую без шлюзов на Android и IOS
- Работает с Алисой, Google Home Assistant, Alexa, Маруся от Mail
- Можно использоваться в сценариях умного дома Tuya Smart / Digma Smart / Smart Life, например в комбинации с датчиком температуры можно создать сценарий: температура понижается ниже 21°С -> включить реле, в который включен обогреватель
- Можно группировать устройства в приложении для удобства управления
- Можно настраивать таймеры, т.е. включать и выключать в заданное время с заданной частотой
- Срабатывании может присылать уведомление на телефон
- Работает также через шлюз SLS
Также есть похожее мини реле, только для умного дома Ewelink — Sonoff MINIR2
Также есть похожее мини реле, только с ваттметром — Wifi реле Aubess 16A
Краткая инструкция по подключению wifi mini реле Aubess:
Подключение можно выполнить одним из способов: с использованием обычного выключателя, проходных выключателей или без выключателя, т.е. использовать модуль как умное реле.
Для подключения нужно использовать фазу и ноль, без нуля не работает
- L-in — в нагрузку (например лампочку)
- N-in — в нагрузку (например лампочку)
- L-out — к сети питания (например розетку)
- N-out — к сети питания (например розетку)
- S1 — вход на выключатель
- S2 — выход из выключателя
- Нажмите и удерживайте кнопку в течение 7 секунд, светодиод начнёт моргать
- В приложении Tuya или Smartlife нажимаете Добавить устройство, затем выбираете Energy, затем Smart meter (Wi-fi) либо через поиск
- Нажимаете далее, вводите пароль от вашей Wifi сети. Ваш телефон должен быть подключен к Wifi сети 2.4 ГГц
- Готово.
- Главная
- Электроника
- Умная электроника
- WiFi Smart Breaker DIY программируемое освещение модуль переключателя Bluetooth-совместимый контроллер вентилятора автоматизации для офиса
- 280 Reviews
- 18 Questions
- Category: Умная электроника >>>
- Supplier: (2670063)
Акционная цена: $ 7.13*
Скидка: 42%
Цена:$ 12.29*
Количество:
-
add to wishlist
Фото
Описание и характеристики
Похожие товары
#WiFi
#Smart
#Breaker
#DIY
#Bluetooth
Programmable fan con
Товары из категории Умная электроника
Original Xiaomi Mijia Intelligent Human Body Sensor Magnetic Smart Home Super Practical Device Accessories Smart Device
$14.27
3Life hand washing household portable smart soap dispenser automatic induction foam washing hand
$21.30
Multimeter LCD Display Screen Repair Parts for FLUKE 15B 17B 18B 15B+ 17B+ 18B+ 115C 116C 117C Multimeter Accessories
$18.00
36mm Mechanical Watch Dial Spare Flower Carved Dial Plate For ETA6497/ ST3600 Manual Winding Movement DIY Parts
$15.67
ШИМ-вентилятор, 12 В, Type-C, 12 Вт
$2.34
TYPE-C умная плата CP2102 2,4 ГГц, двухъядерный Wi-Fi микроконтроллер с Bluetooth для Arduino ESP32S ESP32
$4.88
Беспроводной USB-роутер, 150 Мбит/с, 4G LTE
$19.52
Электрическая гитара MSR по заводской цене, лидер продаж, электрическая гитара, готов к отправке, принимается OEM
$6071.92
| Document ID | 3949608 |
| Application ID | MjTrDFizh/282BHUXuRRWA== |
| Document Description | Users Manual |
| Download: |  |
| Mirror Download [FCC.gov] | |
| Short Term Confidential | No |
| Permanent Confidential | No |
| Supercede | No |
| Document Type | User Manual |
| Display Format | Adobe Acrobat PDF — pdf |
| Filesize | 76.17kB (952136 bits) |
| Date Submitted | 2018-08-03 00:00:00 |
| Date Available | 2018-08-03 00:00:00 |
| Creation Date | 2018-08-02 15:52:20 |
| Producing Software | Acrobat Distiller 11.0 (Windows) |
| Document Lastmod | 2018-08-02 15:52:44 |
| Document Title | Users Manual |
| Document Creator | PScript5.dll Version 5.2.2 |
| Document Author: | toby855 |
Source Exif Data [exif.tools]:
File Type : PDF File Type Extension : pdf MIME Type : application/pdf PDF Version : 1.6 Linearized : No Author : toby855 Create Date : 2018:08:02 15:52:20+08:00 Modify Date : 2018:08:02 15:52:44+08:00 XMP Toolkit : Adobe XMP Core 5.4-c006 80.159825, 2016/09/16-03:31:08 Format : application/pdf Title : Microsoft Word - 英文说明书.docx Creator : toby855 Creator Tool : PScript5.dll Version 5.2.2 Metadata Date : 2018:08:02 15:52:44+08:00 Producer : Acrobat Distiller 11.0 (Windows) Document ID : uuid:f0dce969-8eef-4d87-b50d-321e6303bf99 Instance ID : uuid:cbfb223f-ee6b-477a-8739-b7b12b19f596 Page Count : 7
For this device, Matismart has developed a platform called «Smart Electrical Safety Supervision and Power Management Platform» which has features like Online power management, real-time power efficiency monitoring, and real-time monitoring of electrical circuit parameters (voltage, current, power KWH, etc), and are reported, which help identify where energy savings are required, and further save power bills through analysis of collected data, power consumption analysis.
Features
Device Extendable
This is a modular device that can be extendable as traditional MCB and RCBO. It withstands a maximum current of up to 80A. 1,2,3 & 4 Pole for iMCB are available.
Minimum Space Requirement
Except for Power supply module of 36mm and the communication module of 18mm, the iMCB and iRCBO have an extra 9mm or 18mm control module, different from traditional MCB and RCBO.
Very Simple Installation
All devices are mounted in 35mm Din Rail and connected by connection pins or flexible flat cable. No special tools are required for the entire connection process.
System Compatibility
This system can be compatible with other systems, such as smart homes, fire monitoring systems, energy efficiency management systems, smoke, and voice control, etc.
Electrical Faults Analysis
The system can realize the real-time analysis of all electrical faults of both main and branch lines: short circuits, earth leakage, overload, over/under voltage, overheated, arc fault, etc.
Monitor Electrical Circuit Parameter
The system can realize real-time monitoring of electrical circuit parameters: voltage, current, power, temperature, residual current, and KWH.
Full Protection
This system includes all protections: overload, short circuit, earth leakage, surge, over/under voltage, arcing fault, phase loss, unbalance, and high temperature.
Max. power and Current Setting
The power and current under-rated current power can be adjustable through the App or software platform.
Auto-test of Earth Leakage Current
The device periodically tests the working of the residual current circuit protection, which can be set on a fixed date each month in the APP, rather than the traditional test monthly on-site.
Anti-fraud of Electricity
Technical Specification of Power Supply Module |
||
| Power supply module will offer stable DC power for smart breaker MTS3 and owns class II surge protection. It is also the necessary part for smart breaker MTS3 system. | ||
| Item Code | MTS3-P25 | MTS3-P25D |
| Standards | EN55022, EN55024, EN61000, EN60950, GB4943 | |
| Approvals | CE, CCC | |
| Functions (Vac) | Power Supplier, surge Protection | |
| Rated Voltage Ue (Vac) | 220 | |
| Rated Input Voltage Range (Hz) | 100-265 | |
| Frequency (HZ) (mA) | 50/60 | |
| Rated Input Current (Vac) | 350 | |
| Rated Output Voltage (A) | 12 | |
| Rated Output Current | 2.5 | |
| Type / Test Class of Surge Protection (mm) | 2 / II | |
| Numbers of Modules ( 1 module=18mm) (KA) | 36 (2P) | |
| Max. Discharge Current Imax (8/20) per pole Imax (KA) | 15 | |
| Nominal Discharge Current In (8/20) per pole In | 10 | |
| Max. Working Capacity (Max.numbers of breakers) (mm²) | 10*(iRCBO/ iMCB) | |
| Conductor Cross-sections (mm²) | 38 | |
| Pollution Degree | 2 | |
| Ambient Temperature (ºC) | -15 — +40 | |
| Storage Temperature (ºC) | -25 — +70 | |
| Humidity | < 95% | |
| Altitude | <=2000 | |
| Terminal Connection | Cable / Pin-type busbar | |
| Mounting | Din rail En60715(35mm) by means of fast clip device | |
| Connection | Both from top to bottom or reverse |
Technical Specification of iRCBO |
||
| Power supply module will offer stable DC power for smart breaker MTS3 and owns class II surge protection. It is also the necessary part for smart breaker MTS3 system. | ||
| Item Code | MTS3-R2 | MTS3-R4 |
| Standards | IEC61009.1, GB16917.1 | |
| Approvals | CE, CCC | |
| Approvals | 2P | 4P |
| Rated Voltage Ue (Vac) | 230 | 400 |
| Frequency (HZ) (mA) | 50/60 | |
| Rated Current (A) | 16,20,25,32,40,50,63,80 | |
| Type (wave form of the earth leakage sensed) (mA) | AC | |
| Rated Resdiual Current (I∆n) (Vac) | 30 | |
| Rated Insulation Voltage Ui (A) | 500 | |
| Rated Breaking Capacity acc.to IEC61009 Ultimate Icn | 6000 | |
| Breaking Time Under I∆n | <=0.1 S | |
| Breaking Time Under Icn | <=0.04S | |
| Tripping Characteristic | C (5-10In) | |
| Other Functions | ||
| Over /under voltage protection, warning and alarm | ||
| Max. power and current setting | ||
| Auto test of earth leakage current | ||
| High temperature protection, warning and alarm | ||
| Arcing fault protection, warning and alarm | ||
| Monitor of current, power, voltage in real-time | ||
| Remote control | ||
| Timer | ||
| Meter | ||
| Event record and notice | ||
| Breaking time when voltage is over 265Vac | 10s | |
| Over / Under Voltage Warning | Voltage is higher than 250Vac or lower than 190Vac | |
| Breaking time when the current reach the | 5s | |
| Max.current or power setup the time for switching on automatically after | 5s | |
| Auto-test of earth leakage current (mA) | 30,50,100,1000(adjustable) | |
| Max. Working Capacity (Max.numbers of breakers) (mm²) | 29*(iRCBO/ iMCB) | |
| Electric Life (Times) | 10000 | |
| Mechanical Life (Times) | 20000 | |
| Conductor Cross-sections (mm²) | 38 | |
| Protection Degree | 2 | |
| Numbers of modules (1 module=18mm) | 3 (54mm) | 5(90mm) |
| Ambient Temperature (ºC) | -15 — +40 | |
| Storage Temperature (ºC) | -25 — +70 | |
| Humidity | < 95% | |
| Altitude | <=2000 | |
| Terminal Connection | Cable/Pin-type busbar | |
| Mounting | Din rail En60715(35mm) by means of fast clip device | |
| Connection | Both from top to bottom or reverse |
Technical Specification of iMCB |
||||
| Smart Breakers are the core part of MTS3 smart system,it combine protection, metering, monitor, timer,automation, event record and notice. | ||||
| Item Code | MTS3-M1 | MTS3-M2 | MTS3-M3 | MTS3-M4 |
| Standards | IEC60898, GB10963.1 | |||
| Approvals | CE, CCC | |||
| Poles | 1P | 2P | 3P | 4P |
| Rated Voltage Ue (Vac) | 230/400-240/415 | |||
| Operational Voltage (Vac) | Min.90 Max:250/440 | |||
| Frequency (HZ) | 50 / 60 | |||
| Rated Current (A) | 10,16, 20, 25, 32, 40, 50, 63, 80 | |||
| Rated insulation voltage Ui (Vac) | 500 | |||
| Rated Impulse Withstand Voltage (1.2/50) Uimp (Vac) | 2500 | |||
| Rated Breaking Capacity Acc.to IEC60899 Icn (A) | 6000 | |||
| Breaking Time Under Icn | <=0.04S | |||
| Tripping Characteristic | B (3-5In), C (5-10In), D (10-14In) | |||
| Other Functions | ||||
| Over /under voltage protection , warning and Alarm | ||||
| Max. Power and Current Setting | ||||
| Auto test of earth leakage current | ||||
| High Temperature protection, warning and Alarm | ||||
| Arcing Fault Protection, warning and Alarm | ||||
| Monitor of Current, power, voltage in real-time | ||||
| Remote control | ||||
| Timer | ||||
| Meter | ||||
| Event record and notice | ||||
| Breaking time when voltage is over 263Vac | 10S | |||
| Over / Undder Voltage Warning | when voltage is higher than 250Vac or lower than 190Vac | |||
| Breaking time when the current reach the max.current or power setup | 5s | |||
| Electric Life (Times) | 10000 | |||
| Mechanical Life (Times) | 20000 | |||
| Conductor Cross-sections (mm²) | 38 | |||
| Pollution Degree | 2 | |||
| Numbers of Modules ( 1 module=18mm) | 1.5 (27mm) | 2.5 (45mm) | 4 (72mm) | 5 (90mm) |
| Ambient Temperature (ºC) | -15 — +40 | |||
| Storage Temperature (ºC) | -25 — +70 | |||
| Humidity | < 95% | |||
| Altitude | <=2000 | |||
| Terminal Connection | Cable/Pin-type busbar | |||
| Mounting | Din rail En60715(35mm) by means of fast clip device | |||
| Connection | Both from top to bottom or reverse |
Technical Specification of Communicaiton Module |
|
| Communication module includes wireless and wired mechanism’s. It also functions as hotspot. | |
| Order Code | MTS3-C |
| Product Code | S3-T30/RS485/WIFI/4G/Ethernet |
| Standards | EN301489, EN300328, EN62479, EN60950 |
| Approvals | CE, CCC |
| Types (Vdc) | S3-T30/RS485/WIFI/4G/Ethernet |
| Rated Input Voltage | 12 |
| Numbers of modules (1 module=18mm) | 1 (18mm) |
| Max. working capacity ( Max.numbers of breaker powering) (mm²) | 16, 20, 25, 32, 40, 50, 63, 80 |
| Type (wave form of the earth leakage sensed) | (iRCBO+ iMCB) x 32pcs |
| Conductor Cross-sections | 2 |
| Ambient Temperature (ºC) | -15 — +40 |
| Storage Temperature (ºC) | -25 — +70 |
| Humidity | < 95% |
| Altitude | <=2000 |
| Terminal Connection | Cable / Pin-type busbar |
| Mounting | Din rail EN60715(35mm) by means of fast clip |
| Connection | Both from top to bottom or reverse |
