EN

Express Protect — SV92

EN

Summary

1. Safety instructions ………………………………………………………………………… 5

2. USING YOUR APPLIANCE …………………………………………………………… 12

2.1 Gettingstarted…………………………………………………………………….. 12

2.2 Filling the water tank …………………………………………………………16

2.3 Transportation ……………………………………………………………………… 18

2.4 Settings …………………………………………………………………………………. 19

2.5 Vertical steaming ………………………………………………………………… 23

2.6 Auto-o ………………………………………………………………………………… 25

3. MAINTENANCE AND STORAGE ………………………………………………… 27

3.1 Emptying the scale collector …………………………………………….. 27

3.2 Rinsing the boiler ………………………………………………………………… 29

3.3 Cleaning ……………………………………………………………………………….. 32

3.4 Storage ………………………………………………………………………………….33

4. TROUBLESHOOTING …………………………………………………………………… 34

4

5

Safety instructions

• Please read these instructions carefully before rst use.

This product has been designed for domestic and indoor

use only. Any commercial use, inappropriate use or failure

to comply with the instructions, the manufacturer accepts

no responsibility and the guarantee will not apply.

• Never unplug the appliance by pulling the power cord.

Always unplug your appliance:

– before lling the water tank or rinsing the boiler,

– before cleaning the appliance,

– after each use.

• The appliance will not work without the limescale

collector (depending on model).

• The appliance must be used and placed on a at, stable,

heat and water resistant surface. When you place the iron

on the iron rest, make sure that the surface on which you

place it is stable.

• This appliance is not intended to be used by persons

(including children) with reduced or impaired physical,

sensory or mental capabilities or persons lacking

appropriate knowledge or experience, unless a person

responsible for their safety provides either supervision or

appropriate instructions concerning use of the appliance

prior to its use.

• Children should be supervised to ensure they do not play

with the appliance.

• This appliance may be used by children aged 8 or over and

persons lacking appropriate knowledge or experience

Important recommendations

6

or persons with reduced or impaired physical, sensory

or mental capabilities provided that they have been

thoroughly instructed regarding use of the appliance, are

supervised, and understand the risks involved. Children

shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without

supervision. Keep the iron and its cord out of reach of

children less than 8 years of age when it is energized or

cooling down.

• The surfaces which are marked with this sign, the

soleplate and steam cord are very hot during the use

of the appliance. Do not touch these surfaces before

the appliance has completely cooled down.

• Never leave the appliance unattended when it is

connected to the mains. Before storing the appliance,

once it is unplugged, please wait until it has cooled down

(around 1 hour).

• Do not use any descaling products (vinegar, industrial

descaling products, etc.) to rinse the boiler: they may

damage the appliance.

• Before rinsing the boiler/rinsing the anti scale collector

(depending on model), always make sure that the

appliance is completely cooled down and has been

unplugged for at least 2 hours before unscrewing the

boiler rinse cap/or anti scale collector.

• Warning: if the boiler cap or the boiler rinse cap (depending

on the model), is dropped or severely knocked, have it

replaced by an Approved Service Centre, as it may be

damaged.

• Never ll the appliance directly from the tap.

• The lling, or descaling, or rinsing, or inspection apertures

7

that are under pressure, must not be opened during use.

• The appliance must not be used if it has been dropped,

if it has any visible damage, if it leaks, or if it functions

abnormally in any way. Do not attempt to dismantle

your appliance: have it examined at an Approved Service

Centre to avoid any danger.

• Check the electrical power cord and steam cords for signs

of wear or damage prior to use. If the electrical power

cord or the steam cord is damaged, it must be replaced by

an Approved Service Center to avoid any danger.

• Accessories, consumables and end user replaceable parts must be only

purchased from an Approved Service Centre.

• For your safety, this appliance conforms to all applicable regulations (Low

Voltage Directive, Electromagnetic Compatibility, Environment, etc).

• Your steam generator iron is an electrical appliance: it must be used under

normal conditions of use. It is designed for domestic use only.

• It is equipped with 2 safety systems:

– a pressure release valve designed to avoid excessive pressure. In the event

of malfunction, the valve releases excess steam.

– a thermal fuse to avoid overheating.

• Always plug your steam generator iron:

– into a mains circuit with voltage between 220 V and 240 V (Alternating

current only),

– a socket outlet with an earth connection.

Connecting to the wrong voltage may cause irreparable damage to the

appliance and will invalidate your guarantee.

• Do not use an extension lead. If you accept liability for doing so, only use

an extension lead which is in good condition, has a plug with an earth

connection and is suited to the power rating of the appliance.

• Completely unwind the power cord before plugging into an earthed

socket outlet.

8

• The soleplate of your iron, the steam cord, and the iron rest on the base

unit can reach extremely high temperatures, and can cause burns: do not

touch them. Never touch the electrical power cords with the sole plate of

the iron.

• Always use a vented/mesh ironing board to prevent water spots on clothes

and to avoid hot steam venting sideways.

• Your appliance emits steam, which can cause burns. Always handle the iron

with care, especially when ironing vertically.

Never direct the steam towards people or animals. Never iron clothing on a

person, always use a hanger. Never iron in a seated position with your legs

under the iron board.

• Never immerse your steam generator iron in water or any other liquid.

Never place it under a running tap.

What water to use?

Your appliance has been designed to function using untreated tap water.

If your water is very hard, we recommend you use a mix of 50% untreated

tap water and 50% distilled water available in hardware stores.

• Types of water not to use:

Heat concentrates the elements contained in water during evaporation.

The types of water listed below may contain organic waste, mineral or

chemical elements that can cause spitting, brown staining or premature

wear of the appliance: water from clothes dryers, scented or softened

water, water from refrigerators, batteries, air conditioners, rain water,

boiled, ltered or bottled water. These types of water should not be used

in your TEFAL iron. Also only use distilled water as advised above.

Always remember:

Never use rainwater or water containing additives (like starch, fragrance

or water from domestic appliances). Such additives can aect the steam

properties and at high temperature, form deposits in the steam generator

chamber which are likely to stain your washing and lead to premature

aging of the appliance.

9

PLEASE RETAIN THIS INSTRUCTION

BOOKLET FOR FUTURE REFERENCE

Environment protection rst !

Your appliance contains valuable materials which can be

recovered or recycled.

Leave it at a local civic waste collection point.

1 Scale collector

2 Steam trigger

3 Lock system

4 Water tank

5 Flush accessory

6 Steam cord

7 Control panel

1

7

www.tefal.com

STEAMBOOST

2

3

4

5

6

12

USING YOUR APPLIANCE

2.1 Gettingstarted

• Unlock your steam

generator.

Express Protect is

equipped with a lock

system to hold the iron

onto the base for easy

transport and storage.

• Completely unwind the

power cord and take

the steam cord out of its

storage space.

13

USING YOUR APPLIANCE

• Plug in your steam

generator.

• Fill the water tank with

tap water up to the max

indication. Put the tank

back into the appliance

by pushing in until it

locks into place.

• Always ensure that the

base unit is positioned

close enough to the

ironing surface to avoid

straining and wear of the

steam cord.

14

USING YOUR APPLIANCE

• Press the «ON-OFF» button

on the control panel.

• The «ON-OFF» and the

«Normal» button light

remain ashing while the

appliance is warming up.

OK

ON

• To obtain steam, press

the steam trigger under

the iron handle. The

steam will stop a few

seconds after you release

the button.

• The steam generator is

ready for use. The mode

can still be switched even

when the light ashes.

After around 2 minutes,

the light of the selected

setting ECO / NORMAL /

VERTICAL STEAM remains

lit.

2min

max

15

USING YOUR APPLIANCE

• To release even more

steam, press the steam

trigger under the handle

three times in quick

succession for automatic

sequential steam.

WARNING: Remember

that the soleplate

remains very hot and can

burn.

NO

OK OK

During ironing do not

leave the iron faced

down on the soleplate

or resting on the ush

accessory. For your

safety, place the iron

on the steam generator

base or on its heel.

NO

16

2.2 Filling the

water tank

• Switch o and unplug

the appliance.

• Fill it with tap water

without exceeding the

MAX indicator.

• Push it back into its

housing until you hear a

«click».

• Remove the removable

water tank using the

handle located at the

front of the steam

generator

USING YOUR APPLIANCE

17

• Plug in the appliance.

• Press the «ON-OFF»

button to restart the

appliance.

USING YOUR APPLIANCE

ON

18

2.3 Transportation

Your steam generator

is equipped with a lock

system to hold the iron

onto the base for easy

transport and storage

To transport your steam

generator using the

handle of the iron:

— Put the iron on the

steam generator base

and lift the lock system

over the iron until it

locks into place and you

hear an audible click.

— Hold the iron by the

handle to transport your

steam generator.

USING YOUR APPLIANCE

19

USING YOUR APPLIANCE

Changing modes

• Press the « MODE »

button located on the

control panel to go from

one setting to another.

2.4 Settings

20

• When you press the

MODE button to change

mode, the light of the

new mode ashes while

the steam generator is

adapting temperature

and steam to the new

setting. The steam

generator is ready when

the light stops ashing.

USING YOUR APPLIANCE
